Standards
IEEE 802.3 10BASE-T Ethernet
IEEE 802.3u 100BASE-TX Fast Ethernet
IEEE 802.3ab 1000BASE-T Gigabit Ethernet
ANSI/IEEE 802.3 NWay auto-negotiation
IEEE 802.3x flow control
IEEE 802.3az Energy Efficient Ethernet (EEE)
Layer2 Features
MAC address table: 2K
Auto MDI/MDIX crossover for all ports
Store-and-forward switching scheme
Full/half-duplex for Ethernet/Fast Ethernet speeds
Full-duplex only for Gigabit Ethernet speed
Jumbo Frames: 9000 Bytes
Switching fabric
10 Gbps
Data Transfer Rates
Ethernet: 10 Mbps (half duplex), 20 Mbps (full duplex)
Fast Ethernet: 100 Mbps (half duplex), 200 Mbps (full duplex)
Gigabit Ethernet: 2000 Mbps (full duplex)
Packet Filtering/Forwarding Rates
Ethernet: 14,880 pps per port
Fast Ethernet: 148,800 pps per port
Gigabit Ethernet: 1,488,000 pps per port
RAM Buffer
128 KB
LED Indicators
Per port: Link/Activity/Speed
Per device: Power
Quality of Service (QoS)
Supports 802.1p QoS
4 Queues, Strict Mode
Green features
Energy Efficient Ethernet (EEE) standard
D-Link Green: power saving by cable length detection
RoHS compliant
Power
External 5 V/1 A Level ?V? Power Adapter
Power Consumption (DC input)
Standby: 0.5 W.
Maximum: 2.01 W.
MTBF
1,688,338 hours
Temperature
Operating: 0 to 50 °C
Storage: -10 to 70 °C
Humidity
Operating: 10% to 90% RH non-condensing
Storage: 5% to 90% RH non-condensing
Dimensions (W x D x H)
100 x 98 x 28 mm
Certifications
FCC Class B
ICES-003 Class B
CE Class B
C-Tick Class B
VCCI Class B
cUL
CB
